Cartoning, Case Packing&Palletizing

ALL PRODUCTS

Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine
Automatic Multifunctional Heat Shrink Sealing Machine

Automatic Multifunctional Heat Shrink Sealing Machine

 L POF Shrink Film Box/Tray/Bag/Cans/Film/Case Sealer

Spu:
1601619553591
Inquiry
  • Overview
  • Recommended Products
Product Overview

Fully Automatic L Type Tray/Bag Sealer
Sealing Packing/Packaging/Package Machine

Machine allows a simple and precise control of all the machine operations, such as:
- Possibility of storing up to 10 different operation programs
- Automatic control of the sealing bar height - double adjustment of the sealing blade temperature, both lengthways and broadways
- Possibility of packing single packs or multipacks
- Speed of conveyors electronically adjustable from the control panel

Features
- Motorized center seal system as standard
- Piece counter, batch production setting possible
- Measurement of the pack length
-Real-time output
- Control of irregular packs
- Reduced power consumption
- Packing film requirement: Polyolefin, polyethylene micro perforated film, thickness from 10 to 50 μ
- Compliance with CE regulations

Available options:
1. Kissing Belt
2. Mark reading device for printed film
3. Stainless Steel Case
4. In-flow and out-flow photocells
5. In feed and out feed conveyors
FEATURES AT A GLANCE
- Motorized center seal system as standard
- Piece counter, batch production setting possible
- Measurement of the pack length
-Real-time output
- Control of irregular packs
- Reduced power consumption
- Packing film requirement: Polyolefin, polyethylene micro perforated film, thickness from 10 to 50 μ
- Compliance with CE regulations

automatic multifunctional heat shrink sealing machine-0
automatic multifunctional heat shrink sealing machine-1

automatic multifunctional heat shrink sealing machine-2

automatic multifunctional heat shrink sealing machine-0

PRODUCT SPECIFICATIONS
Item
HYLA-6000/ HYLA-6000CS
HYLA-8000/HYLA-8000CS
Power supply/ Installed power
220 - 240 V, 1PH - N - PE, 50/60 Hz/ 3200 W
Compressed air pressure/ Compressed air consumption
5 bar/ 6 Nl/p
Sealing bar Dimension
610 x 480 mm
860 x 670 mm
Maximum pack height
200 mmfor center seal
250 mmfor center seal
Speed of conveyors
10 - 30 M/min
Average output per hour
600 - 2400
600 - 1800
Maximum size of film reel
600 - ø 300 mm
Machine size
L2040 × W1550 × H1340 mm
L2580 × W1840 × H1620 mm
Packed machine size
L2160 × W1730 × H1620 mm
L2469 × W1740 × H1340 mm
Machine weight
NW: 610 Kg GW: 850 Kg
NW: 750 Kg GW: 930 Kg
